Non-medical-grade electronic adhesives and encapsulants for consumer wearable device assembly cure quickly with light and are designed for applications where skin proximity and sensitivity are a concern. The 9200-W product series is formulated with low sensitizing ingredients, with certain skin irritants such as isobornyl acrylate (IBOA) removed. The materials feature good bonding ability, flexibility, and weatherability and are made for lens alignment, structural bonding, encapsulation of components found in AR/VR headsets, earbuds, and other wearable devices.

  • Cure using UV/LED light
  • Low sensitizing ingredients and skin friendly
  • Light + moisture cure products for shadow area curing
  • One component, so no mixing is required
  • For wearing on the body for short- or long-term periods
Unit of Measure

Specifications

Brands

 N/A Dymax®

Nominal Viscosity

 N/A 20,000 cP

Uncured Appearance

 N/A Colorless

Cured Elongation at Break

 N/A 191 %

Cured Linear Shrinkage

 N/A 0.68 %

Recommended Substrates

 N/A Acrylonitrile Butadiene Styrene (ABS) Flame Retardant (FR-4) Liquid Crystal Polymer (LCP) Polycarbonate (PC)

Cured Durometer Hardness

 N/A D63

Features

Features

 N/A
  • Free of IBOA (isobornyl acrylate), a known skin sensitizer
  • Cures in seconds with UV/Visible light
  • One-part formulation - no mixing
  • No solvents added

Additional Information

Additional Information

 N/A Low-Stress Plastic Bonding Adhesive for Camera Module Assembly

9211-W low-stress plastic bonding adhesive cures with UV/Visible light energy for ultra-fast bonding and sealing of camera module components found in consumer wearable devices.

This product forms excellent bonds to PC, LCP, ABS, and FR4 substrates and is specifically designed for CCM applications and camera module barrel fixtures.

One-component and with no solvents added, 9211-W is a plastic bonding adhesive formulated without IBOA and with low-sensitizing ingredients to be as safe as possible when wearables are touching or close to the skin.

9211-W adhesive is in full compliance.

For medical wearables assembly, see the Dymax® 2000-MW series of biocompatible IBOA- and TPO-free adhesives.
